Octagonal Blender
Octagonal Blender Manufacturer
An octagonal blender is an eight-sided, tumble-type machine used to blend dry powders or granules uniformly. It provides very gentle, dust-free mixing without deforming the shape or size of the powder or granules. Padmatech Industries’ octagonal blenders are high-performance industrial mixing systems widely used across the pharmaceutical, food processing, nutraceutical, cosmetics, chemical, agrochemical, and fertilizer industries. Designed for efficient and uniform blending, these machines offer large batch capacities, consistent mixing performance, easy cleaning, and minimal product retention, ensuring smooth and hygienic operations.
Equipped with robust safety features and advanced interlocking systems, our octagonal blenders provide reliable and safe operation while meeting the demanding requirements of modern manufacturing environments. For over 21 years, Padmatech Industries has been a trusted octagonal blender and process equipment manufacturer in India. We have supplied octagonal blenders to many clients across industries, each customized to their process needs. Share your requirements, and our team will get back to you with the right configuration and quotation.
Working Principle
In an octagonal blender, material is loaded at the set position through the material entry door. After the door is closed, all limit switches are interlocked, and the machine rotates at a speed of 10–30 RPM, depending on the capacity.
Mixing takes place mainly due to the octagonal shape of the bowl and the baffles provided. After the set time has elapsed, the blender stops at a specific position, and the material is discharged.
Octagonal Blender Design
The name Octagonal Blender itself indicates the design and shape of the blender. An octagonal blender has eight sides for effective mixing. The main design parameters and selection are based on 100% drainability of the powder. The blender is provided with a suitable loading and unloading station operated with the help of a proximity switch.
All working areas are guarded by a railing platform and controlled automatically by limit switches. The design thickness mainly depends on the powder properties, such as the type of powder, bulk density, capacity, and material of construction (MOC).
Applications of Octagonal Blender
Pharmaceutical: Mixing active pharmaceutical ingredients (APIs) and blending dry powder formulations.
Nutraceutical: Uniform dry mixing of dietary supplements, protein powders, and herbal granules.
Chemical: Blending dry powders, crystals, and granules into a homogeneous mixture for chemical-industry applications, including specialty chemicals, pigments, dyes, detergents, and other powdered products.
Food Processing: Homogenizing drink powders, flavoring agents, spices, instant beverage powders, powdered milk, soups, and nutritional supplements.
Cosmetics: Uniform mixing of face powders, talc, cosmetic pigments, and other dry personal care ingredients.
Why Choose Padmatech Industries for Octagonal Blender
With over 21 years of experience in process equipment manufacturing, Padmatech Industries builds octagonal blenders that deliver gentle, uniform mixing for powders and granules in pharma, chemical, and biotech applications. Backed by a world-class manufacturing facility, ASME U-Stamp and ISO certifications, complete documentation, flexible customization, and a 98% uptime promise, our blenders give you consistent performance, batch after batch.
Surface finish up to 240 grit- Low power consumption
- Removable baffles, easy cleaning, and zero wastage
- Dust-free charging and controlled discharge
- Suitable for multiple products
- Zero dead material retention
Capacity
500 L to 5000 L
Material of Construction
SS 304 / SS 316 / SS 316L, GMP Grade
Rotation Speed
Slow speed, 10 to 30 RPM, depending on batch size
Internal Finish
Mirror-polished stainless-steel surfaces
Discharge
Dust-free butterfly valve or slide valve for smooth discharge
Safety Features
Safety guard rails with safety interlocks
Optional Accessories
Loading systems, control panel, flameproof motor, etc.
Frequently Asked Questions
500 liters to 5,000 liters (or roughly 500 kg to 5,000 kg per batch).
The material of construction mainly depends on the chemical properties of the powder. Stainless steel, specifically Grade 304 or 316, is the most widely used material for dry powder blending equipment.
Yes, an octagonal blender is suitable for food-grade applications when manufactured with food-safe stainless steel, such as SS 304 or SS 316, and mirror-polished internal surfaces.
Octagonal blenders are ideal for blending dry powders and granules, particularly free-flowing materials that require low-shear mixing.
Yes, octagonal blenders can be equipped with WIP/CIP systems as an optional, custom-engineered configuration rather than as a standard feature.
An octagonal blender includes multiple safety mechanisms such as safety railings & limit switches, interlocking systems, emergency stop switches, and flameproof electricals (optional) to ensure safe and reliable operation.
